Sumix aims Manta-W+ inspection scope at 3M expanded beam optical connector

April 22, 2019
Lightwave's Stephen Hardy reports that Sumix and 3M have collaborated to enable the Sumix Manta-W+ fiber inspection microscope to evaluate 3M Expanded Beam Optical Connector implementations.

Sumix Corp., working with 3M, has developed an adapter for its Manta-W+ fiber inspection microscope that enables the instrument to inspect 3M’s recently announced Expanded Beam Optical Connector. While the new fiber-optic connector is designed to be less sensitive to dust and other particles on the fiber endface, installations will still need inspection, Sumix points out.

The Expanded Beam Optical Connector leverages a non-contact optical coupling which, in combination with the connector design, reduces sensitivity to dust and improves signal integrity, according to 3M.

See Also: 3M says expanded beam ferrule, connector system cuts dust sensitivity, reduces maintenance: Video

The design reduces the need for maintenance and cleaning, which should be a boon in applications where the connector will be hard to access, such as onboard optics deployments, a 3M source said at OFC 2019. However, the need for inspection isn’t removed entirely (particularly at initial installation), which is where the Manta-W+ fiber scope comes in.

Sumix says it collaborated with 3M on the design and development of the adapter. It also has worked with 3M on pass/fail criteria. The result is the adapter and new software, which Sumix says will find use in data center, laboratory, and manufacturing applications. The Manta-W+ fiber inspection microscope earned a 4.0 rating in the 2019 Lightwave Innovation Reviews.-- Stephen Hardy,LightwaveOnline

Blog: Is 3M getting pulled back into Comms?
